Model |
|
CSTP-150 |
CSTP-200 |
CSTP-300 |
Solar collector |
Number of tubes Aperture
area Coating Header Wall insulation |
15 1.5m2 Selectivity Cu
22 mm 40 mm mineral wool |
20 2.00m2 Selectivity Cu
22 mm 40 mm mineral wool |
26 2.6m2 Selectivity Cu
22 mm 40 mm mineral wool |
Tank |
Contents Diameter Length Operating
pressure Insulating Material Insulation
thickness Connections Empty weight |
150L 540mm 1000mm 6bar Rigid
polyurethane foam 50mm 3/4" 40kg |
200L 540mm 1500mm 6bar Rigid
polyurethane foam 50mm 3/4" 55kg |
150L 540mm 1000mm 6bar Rigid
polyurethane foam 50mm 3/4" 65kg |
Frame |
Material Corrosion
protection Use |
Powder coated
steel Galvanised Elevated and parallel roof
installation |
Connection pipe |
Length Diameter Insulating
material Insulation thickness |
1,000 mm stainless
steel pipe Dia.22 mm Elastomer rubber with
protective PE
film 20mm |
